| AMD CPU Cooler |
|
Igloo A330 Series |
 |
|
|
| |
|
| |
Highlighted features
 High Quality Aluminum Alloy
High Fin Density
PWM Version: Fan speed increase with the increase of CPU loading
Constant Fan Speed Version: The best price-performance
Weight / noise performance
Easy to install
|
| |
| Specifications |
|
| Model |
Igloo A330 Silent (U) |
Igloo A330 Light (U) |
Igloo A330 (U) |
Igloo A330 PWM (U) |
| Socket Type |
AMD FM1, FM2, AM2, AM2+, AM3 |
| CPU Compatibility |
A4-3400, A6-3650, A8-3850 (100W)
Athlon X4-750K, A8-5600K, A10-5800K (100W)
Phenom™ II X2, X3, X4, and X6 Processors (95W)
Phenom™ X3, X4 Cores Processors (95W)
Athlon™ II X2, X3, X4 Processor (95W) |
| Dimension (mm) |
76.5(W)×76.5 (L)×52.3(H) |
| Weight (grams) |
220 |
| Fan |
Bearing Type |
Ultra Entering Bearing |
| Rated Voltage |
DC 12 V |
| Dimension (mm) |
80 x 80 x 25 |
| Speed(RPM) |
2000(±10%) |
2600 (±10%) |
3200(±10%) |
PWM 800(±300 RPM)~3600(±10%) |
| Airflow (CFM) |
26 |
35.5 |
44.1 |
Max. 50 |
| Noise (dBA) |
20 |
25 |
32 |
15~38 |
| MTBF (hour/25 °C ) |
50,000 |
50,000 |
50,000 |
50,000 |
| Interface Material |
High Efficiency Thermal Compound |
|
| |
| |
| |
| |
| |
|
|
|
| |
 |
| |
| |
|
|
