| DC Fan / GT JET |
|
Server Fan |
|
|
Download |
.jpg "Case Fan GT JET 6056 for Servers and Data Centers") |
| |
|
| |
| |
 Key Features |
- Integrated Stator Blade Frame: Optimizes airflow direction and corrects vortex patterns, significantly reducing turbulence and energy loss.
- Dual ball bearing construction: Engineered for high-temperature, high-speed, and long-duration reliability.
- The copper tube enhances heat dissipation and shaft stability, improving fan durability and cooling efficiency.
- Supports intelligent speed control (PWM) and fault feedback (option).
|
| |
| Specifications |
| Model (TYPE A) |
Rated
Voltage
(VDC) |
Rated
Current
(A) |
Power
Consumption
(Watts) |
Speed
Inlet/outlet
(rpm) |
Air Flow
(CFM) |
Static
Pressure
(mmH2O) |
Noise
(dBA) |
| GT-A06038B12M |
12 |
0.49 |
5.88 |
10,000 |
43.12 |
30.91 |
51.7 |
| GT-A06038B12H |
12 |
1.34 |
16.08 |
14,000 |
64.25 |
62.03 |
59.3 |
1. Material：Plastic PBT (UL：94V-0) ;
2. Bearing Type：Two ball bearing.
3. Protection：Auto-Restart.
4. Operating Temperature：-20 ~ 70 °C. |
|
| |
| |
| Dimension |
.jpg) |
| |
| P-Q Curve: |
.jpg) |
| |
| |
| |
| |
|
.jpg)
.jpg)
.jpg)
.jpg)
