| Model |
GT8025-EDLA1 |
GT8025-HDLA1 |
GT8025-BDLA1 |
| Operation Voltage (VDC) |
6.0 ~ 13.8 |
6.0 ~ 13.8 |
6.0 ~ 13.8 |
| Rated Voltage (VDC) |
12.0 |
12.0 |
12.0 |
| Rated Current (AMP) |
1.10 |
0.10 |
0.10 |
| Input Power (W) |
1.20 |
1.20 |
1.20 |
| Bearing System |
Entering Bearing |
Hydrodynamic Bearing |
Two-Ball Bearing |
| Fan Speed (RPM) |
1700 ± 10% |
1700 ± 10% |
1700 ± 10% |
| Air Volume (CFM) |
26.3 |
26.3 |
26.3 |
| Airflow ( m³ /min) |
0.75 |
0.75 |
0.75 |
| Static Pressure (mm-H2O) |
1.28 |
1.28 |
1.28 |
| Noise Level (dBA) |
18.0 |
18.0 |
18.0 |
| Safety |
CE, UL, TUV |
CE, UL, TUV |
CE, UL, TUV |
| MTBF (hours / 25°C ) |
35,000 |
80,000 |
50,000 |
| Dimension (mm) |
80 x 80 x 25 |
80 x 80 x 25 |
80 x 80 x 25 |
| Weight (gram) |
74.5 |
75.5 |
72.5 |
|
|
|
| |
|
|
| |
|
|
| |
|
| Model |
GT9225-EDLA1 |
GT9225-HDLA1 |
GT9225-BDLA1 |
| Operation Voltage (VDC) |
6.0 ~ 13.8 |
6.0 ~ 13.8 |
6.0 ~ 13.8 |
| Rated Voltage (VDC) |
12.0 |
12.0 |
12.0 |
| Rated Current (AMP) |
0.13 |
0.13 |
0.13 |
| Input Power (W) |
1.56 |
1.56 |
1.56 |
| Bearing System |
Entering Bearing |
Hydrodynamic Bearing |
Two-Ball Bearing |
| Fan Speed (RPM) |
1600 ± 10% |
1600 ± 10% |
1600 ± 10% |
| Air Volume (CFM) |
35.8 |
35.8 |
35.8 |
| Airflow ( m³ /min) |
1.02 |
1.02 |
1.02 |
| Static Pressure (mm-H2O) |
1.34 |
1.34 |
1.34 |
| Noise Level (dBA) |
18.5 |
18.5 |
18.5 |
| Safety |
CE, UL, TUV |
CE, UL, TUV |
CE, UL, TUV |
| MTBF (hours / 25°C ) |
35,000 |
80,000 |
50,000 |
| Dimension (mm) |
92 x 92 x 25 |
92 x 92 x 25 |
92 x 92 x 25 |
| Weight (gram) |
93.5 |
94.5 |
92.5 |
|
|
|
| |
|
|
| |
|
|
| |
|
| Model |
GT12025-EDLA1 |
GT12025-HDLA1 |
GT12025-BDLA1 |
| Operation Voltage (VDC) |
7.5 ~ 13.8 |
7.5 ~ 13.8 |
7.5 ~ 13.8 |
| Rated Voltage (VDC) |
12.0 |
12.0 |
12.0 |
| Rated Current (AMP) |
0.12 |
0.12 |
0.12 |
| Input Power (W) |
1.44 |
1.44 |
1.44 |
| Bearing System |
Entering Bearing |
Hydrodynamic Bearing |
Two-Ball Bearing |
| Fan Speed (RPM) |
950 ± 150 |
950 ± 150 |
950 ± 150 |
| Air Volume (CFM) |
36.0 |
36.0 |
36.0 |
| Airflow ( m³ /min) |
1.02 |
1.02 |
1.02 |
| Static Pressure (mm-H2O) |
0.75 |
0.75 |
0.75 |
| Noise Level (dBA) |
18.0 |
18.0 |
18.0 |
| Safety |
CE, UL, TUV |
CE, UL, TUV |
CE, UL, TUV |
| MTBF (hours / 25°C ) |
35,000 |
80,000 |
50,000 |
| Dimension (mm) |
120 x 120 x 25 |
120 x 120 x 25 |
120 x 120 x 25 |
| Weight (gram) |
144.5 |
146.5 |
143.5 |
|
|
|
| |
|
|
| |
|
|
| |
 |
|
| |
|
|
| |
|
|
| |
 |
|
| |
GlacialTech devotes itself to designing a series of PC case fans which focus on the low noise and high air flow, bring the sound quality and is suitable for most PC system configurations. |
|
|
| |
| |
|
