| AMD CPU Cooler |
|
Igloo A200 Series |
 |
|
|
| |
|
| |
Highlighted features
 High Quality Aluminum Alloy
High Fin Density
PWM Version: Fan speed increase with the increase of CPU loading
Constant Fan Speed Version: The best price-performance
Weight / noise performance
Easy to install |
| |
| Specifications |
|
| Model |
Igloo A200 Light ( E ) |
Igloo A200 ( E ) |
Igloo A200 PWM ( E ) |
| Socket Type |
AMD FM1, FM2, AM2, AM2+, AM3 |
| CPU Compatibility |
A4-A3400, A6-A3600, A8-3800 (65W)
Athlon X4-740, A4-5300, A6-5400K, A8-5500, A10-5700 (65W)
Phenom™ II X3, X4 Processors (65W)
Phenom™ X3, X4 Cores Processors (65W)
Athlon™ II X2, X3, X4 Processor (65W) |
| Dimension (mm) |
76(W)×68(L)×42.3(H) |
| Weight (grams) |
165 |
| Fan |
Bearing Type |
Entering Bearing |
| Rated Voltage |
DC 12 V |
| Dimension (mm) |
70 x 70 x 15 |
| Speed(RPM) |
2600 (±10%) |
3200(±10%) |
PWM 1200(±300 RPM)~
3600(±10%) |
| Airflow (CFM) |
18.4 |
22.4 |
Max. 27.6 (±10%) |
| Noise (dBA) |
21 |
26 |
Max. 34 |
| MTBF (hour/25 °C ) |
3 0,000 |
3 0,000 |
3 0,000 |
| Interface Material |
High Efficiency Thermal Compound |
|
| |
| |
| |
| |
| |
|
|
|
| |
 |
| |
| |
|
|
