Multi-platform Solutions / Side Blowing |
|
Igloo SHP4-12 |
|
|
|
|
|
|
Features |
Four high heat capacity heat-pipes are used.
Heat-pipes contact CPU directly.
PWM fan is used.
Easy to install. |
|
|
Specifications |
|
Model Name |
Igloo SHP4-12 |
Socket Type |
Intel LGA1700 / 1200 /115X (up to 150W)
AMD AM4/AM5 (up to 170W+) |
Dimension (mm) |
120×67×150 |
Weight (gram) |
380 |
Heatsink Material |
ALUMINUM + COPPER |
Fan |
Bearing Type |
Hydro-Dynamic |
Rated Voltage |
DC12V |
Dimension (mm) |
120×120×25 |
MTBF (hour/25°C) |
40,000 |
Speed(RPM) |
PWM 900~2500 (4 pin, controllable) |
Airflow (CFM) |
105 |
Noise (dBA) |
43 |
Safety |
CE |
Cable length(mm) |
300 ±10 |
Interface Material |
High Efficiency Thermal Compound |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
