| Model Name |
Igloo 1021m1 (E) |
| Socket Type |
Screw hole pitch 75 x 75 mm (or 78 x 78 mm, optional) |
| CPU Compatibility |
Intel® Core™ Ultra processors |
| Dimension (mm) |
89.4 × 89.4 × 21 |
| Fan |
Bearing Type |
Hydro-Dynamic |
| Dimension (mm) |
80 × 80 × 11 |
| Speed (rpm) |
PWM 1500~3000RPM |
| Airflow (CFM) |
22 |
| Noise (dBA) |
28 |
| Rated voltage (VDC) |
12 |
| MTBF (hours: 25°C/ RH65%) |
40000 |
| Safety |
CE |
| Cable length (mm) |
150 |
| Material-Heat sink |
Aluminum |
| Material-Thermal compound |
High Efficiency Thermal Compounds |
