Intel LGA 1150/1151/1155/1156   Igloo 1100CU Series
Model Igloo 1100CU
Silent (E)/(2B)
Igloo 1100CU
Light (E)/(2B)
Igloo 1100CU
Igloo 1100CU
PWM (E)/(2B)
Socket Type Intel LGA 1150/1151/1155/1156
CPU Compatibility 9th generation Intel® Core™ i9 (up to 127W)
10th generation Intel® Core™ i7 (up to 95W)
10th generation Intel® Core™ i5 (up to 65W)
10th generation Intel® Core™ i3 (up to 95W)
9th gen Intel® Core™ vPro™ (up to 65W)
Dimension (mm) Ф 95×67
Weight (grams) 380
Fan Bearing Type Ultra Entering Bearing / Two Ball Bearing
Rated Voltage DC 12V
Dimension (mm) 80 x 80 x 25
MTBF(hour/25°C) 50,000 hours / 25°C
Speed(RPM) 2000 2600 3200 PWM 800~3600
Airflow (CFM) 26.0 35.5 44.1 50.082 (max.)
Noise (dBA) 20 25 32 15~38
Safety UL, CE
Interface Material High Efficiency Thermal Compound
