| Model |
Igloo 1100CU
Silent
(E)/(2B) |
Igloo 1100CU
Light
(E)/(2B) |
Igloo 1100CU
(E)/(2B) |
Igloo 1100CU
PWM
(E)/(2B) |
| Socket Type |
Intel LGA 1150/1151/1155/1156 |
| CPU Compatibility |
9th generation Intel® Core™ i9 (up to 127W)
10th generation Intel® Core™ i7 (up to 95W)
10th generation Intel® Core™ i5 (up to 65W)
10th generation Intel® Core™ i3 (up to 95W)
9th gen Intel® Core™ vPro™ (up to 65W) |
| Dimension (mm) |
Ф 95×67 |
| Weight (grams) |
380 |
| Fan |
Bearing Type |
Ultra Entering Bearing / Two Ball Bearing |
| Rated Voltage |
DC 12V |
| Dimension (mm) |
80 x 80 x 25 |
| MTBF(hour/25°C) |
50,000 hours / 25°C |
| Speed(RPM) |
2000 |
2600 |
3200 |
PWM 800~3600 |
| Airflow (CFM) |
26.0 |
35.5 |
44.1 |
50.082 (max.) |
| Noise (dBA) |
20 |
25 |
32 |
15~38 |
| Safety |
UL, CE |
| Interface Material |
High Efficiency Thermal Compound |
